Valve Recess Depth 1 (VT) 1.05 mm

Length [mm] (L) 74.85 mm

Valve Recess Depth 2 (VT) 1.25 mm

Compression height (KH) 44.85 mm

Valve Recess Diameter 2 37.0 mm

Valve Recess Diameter 1 40.0 mm

Recess Volume 6.6 cm³

Combustion Chamber Depth (MT) 9.05 mm

Top land height [mm] (F) 12.8 mm

Combustion chamber offset (MV) 19.0 mm

Distance between bosses (AA) 22.15 mm

Pin O.D. (BoØ) 26.0 mm

Pin I.D. 14.0 mm

Pin Length (BoL) 55.0 mm

Surface Graphite coated

Material M124

Ferrostan false

Casting Number 87 V 89

Ring Carrier (RT) RT

Cooling gallery (KK) no

Recess for oil cooling nozzle (AK) no

Piston Skirt Clearance 0.04 mm
