missing 1 snap ring
Length [mm] 87,000
Cylinder Bore [mm] 92,90
Bolt Ø [mm] 28
Supplementary Article/Info 2 with piston ring carrier
Component Number 08-521100-00
Compression Height [mm] 50,300
Bolt length [mm] 80
Recess Depth 1 [mm] 1,500
Valve pocket depth 1 [mm] 0,800
Standard Size [STD]
Piston Clearance [mm] 0,150
| MAKE | VARIANT | ENGINE | |
|---|---|---|---|
| ASKAM (FARGO/DESOTO) | DODGE/FARGO AS250/DESOTO Pickup [09/93 - 02/02] | Diesel 2.5 TD 76KW 103HP [09/93 - 02/02] | |
| NISSAN | CABSTAR (F22, H40) [01/82 - 09/93] | Diesel 2.5 TD (F22) 59KW 80HP [10/82 - 06/92] | |
| NISSAN | CABSTAR (F22, H40) [01/82 - 09/93] | Diesel 2.5 TD 55KW 75HP [01/89 - 12/92] | |
| NISSAN | CABSTAR (F23, H41, H42) [07/92 - 09/11] | Diesel 2.5 D 56KW 76HP [07/92 - 12/00] | |
| NISSAN | NAVARA (D21) [09/85 - 03/08] | Diesel 2.5 D 4x4 55KW 75HP [01/86 - 08/87] | |
| NISSAN | NAVARA (D21) [09/85 - 03/08] | Diesel 2.5 D 4x4 59KW 80HP [01/86 - 03/08] | |
| NISSAN | NAVARA (D22_) [01/97 -] | Diesel 2.5 TD 59KW 80HP [02/98 - 10/01] | |
| NISSAN | PICK UP (D21) [09/85 - 12/08] | Diesel 2.5 D 4WD 61KW 83HP [03/96 - 02/98] | |
| NISSAN | PICK UP (D21) [09/85 - 12/08] | Diesel 2.5 D 61KW 83HP [08/92 - 02/98] | |
| NISSAN | PICK UP (D21) [09/85 - 12/08] | Diesel 2.5 D 4WD 59KW 80HP [08/87 - 02/98] |
