Description
| Voltage [V] | 11 | |
|---|---|---|
| Connector type | M4 | |
| Diameter [mm] | 5 | |
| Thread Size | M10x1,25 | |
| Overall Length [mm] | 89 | |
| Spanner Size | 12 mm | |
| Glow Plug Design | Pencil-type Glow Plug | |
| Packing Type | Box | |
| Fitting Depth [mm] | 23,85 | |
| Failure Moment [Nm] | 35 | |
| Tightening torque from [Nm] | 15 | |
| Tightening torque to [Nm] | 20 | |
| MAKE | VARIANT | ENGINE |
| ISUZU | CAMPO (KB) [04/77 - 12/91] | Diesel 2.2 D (KBD27) 39KW 53HP [04/86 - 12/90] |
| ISUZU | CAMPO (KB) [04/77 - 12/91] | Diesel 2.2 D 4WD (KBD42, KBD47) 39KW 53HP [01/83 - 12/90] |
| ISUZU | CAMPO (KB) [04/77 - 12/91] | Diesel 2.2 D (KBD27) 45KW 61HP [01/83 - 12/91] |
| ISUZU | GEMINI (JT) [10/84 - 12/90] | Diesel 1.5 D 37KW 50HP [02/88 - 12/90] |
| ISUZU | GEMINI Saloon (JT) [09/84 - 06/90] | Diesel 1.5 D 37KW 50HP [02/88 - 12/89] |
| ISUZU | TROOPER I Open Off-Road Vehicle (UBS) [01/83 - 12/91] | Diesel 2.2 TD (UBS52) 53KW 72HP [03/84 - 12/91] |
| ISUZU | TROOPER I Open Off-Road Vehicle (UBS) [01/83 - 12/91] | Diesel 2.2 D 4x4 39KW 53HP [05/84 - 07/89] |
| OPEL | CAMPO (TF0, TF1) [08/87 - 06/02] | Diesel 2.2 D 4x4 (TFS52) 45KW 61HP [08/87 - 08/90] |
| OPEL | CAMPO (TF0, TF1) [08/87 - 06/02] | Diesel 2.2 D (TFR52) 45KW 61HP [08/87 - 08/90] |
| OPEL | CAMPO (TF0, TF1) [08/87 - 06/02] | Diesel 2.2 D 45KW 61HP [09/90 - 08/92] |
| OPEL | CAMPO (TF0, TF1) [08/87 - 06/02] | Diesel 2.2 D 4x4 45KW 61HP [09/90 - 08/92] |
| OPEL | CORSA A Hatchback (S83) [09/82 - 03/93] | Diesel 1.5 D (F08, M08, F68, M68) 37KW 50HP [09/87 - 03/93] |
| OPEL | CORSA A Hatchback Van (S83) [02/86 - 09/94] | Diesel 1.5 D (F08, W5L) 37KW 50HP [06/87 - 04/89] |
| OPEL | CORSA A TR (S83) [09/82 - 03/93] | Diesel 1.5 D (F11, M11, F19, M19) 37KW 50HP [10/87 - 11/92] |
| OPEL | VECTRA A (J89) [08/88 - 12/95] | Diesel 1.7 TD (F19, M19) 60KW 82HP [03/90 - 11/95] |
| OPEL | VECTRA A Hatchback (J89) [04/88 - 12/95] | Diesel 1.7 TD (F68, M68) 60KW 82HP [03/90 - 11/95] |
| SSANGYONG | KORANDO (K5, K9) [12/88 - 05/97] | Diesel 2.2 D 50KW 68HP [12/88 - 12/96] |
| VAUXHALL | CAVALIER Mk III Hatchback (J89) [09/88 - 11/95] | Diesel 1.7 TD 60KW 82HP [09/88 - 11/95] |
| VAUXHALL | CAVALIER Mk III Saloon (J89) [08/88 - 11/95] | Diesel 1.7 TD 60KW 82HP [09/88 - 11/95] |
| VAUXHALL | NOVA Hatchback (S83) [05/83 - 03/93] | Diesel 1.5 D 37KW 50HP [09/87 - 03/93] |
| VAUXHALL | NOVAVAN Hatchback Van (S83) [01/90 - 10/94] | Diesel 1.5 D 37KW 50HP [01/91 - 10/94] |
